Autel

EVO II Dual 640T V2 Rugged Bundle, 8k UHD Dual Camera with thermal imaging sensor, 16X digital zoom, Radiometric Temperature Detection, 360 degrees Obstacle Avoidance and Dynamic Tracking

EVO II Dual 640T V2 Rugged Bundle, 8k UHD Dual Camera with thermal imaging sensor, 16X digital zoom, Radiometric Temperature Detection, 360 degrees Obstacle Avoidance and Dynamic Tracking

Regular price $5,899.00 USD
Regular price Sale price $5,899.00 USD
Sale Sold out
Shipping calculated at checkout.

The EVO II Dual 640T is a High-Quality Professional drone equipped with a 8K UHD Dual Camera with thermal imaging sensor.  Its 19 groups of sensors grant it a 360° obstacle avoidance system. The drone also features a  Radiometric Temperature Detection system, 13mm lens and 16x digital zoom capable of recognizing subjects at up to 100meters

  • Dual Camera design with a thermal imaging sensor
  • Thermal imaging sensor has a resolution of up to 640x512@30 fps
  • Support 10 Thermal color palettes, 30Hz refresh rate and Picture-in-Picture mode
  • 13mm lens and 16x digital zoom capable of recognizing subjects at up to 100m
  • Radiometric Temperature Detection
  • 1/2" CMOS sensor capable of 48 MP photos and 8K Ultra HD Videos
  • 360° obstacle avoidance with 19 groups of sensors
  • Industry-leading 38 minutes flight time
  • Transmission range of 9KM


Specifications

Aircraft

Takeoff weight 1191 g
Max takeoff weight 2000 g
Wheelbase 397 mm
Size(L*W*H) 230*130*108mm(folded)
457*558*108mm(unfolded)
Maximum service ceiling altitude 7000 m
Max ascent speed 8 m/s (Ludicrous)
Max descent speed 4 m/s (Ludicrous)
Max horizontal flight speed 20m/s (Ludicrous)
Max flight distance (no wind) 25 km
Max tilt angle 33° (Ludicrous)
Max angular velocity 120°/s
Max flight time (no wind) 40 min
Max hovering time (no wind) 35 min
Operating temperature range -10℃ ~ 40℃
Maximum resistance to wind Level 8
Operating frequency 902-928MHz (FCC Only)
2.400-2.4835GHz
5.725-5.850GHz (non-Japan)
5.650-5.755GHz (Japan Only)
Transmission power 900M
FCC/ ISED:≤31dBm
2.4G
FCC/ ISED:≤32dBm
SRRC/CE/MIC/RCM:≤20dBm
5.8G (non-Japan) ; 5.7G (Japan)
FCC/ISED/SRRC/MIC:≤33dBm
CE/ RCM:≤14dBm
Hovering accuracy Vertical: ±0.1 m (when the visual positioning is working normally);
±0.5 m (when GPS works normally)
Horizontal: ±0.3 m (when the visual positioning is working normally);
±1.5 m (when GPS works normally)
GNSS GPS/Beidou/Glonass/Gallieo
Internal storage 8GB
SD storage max. support 256GB (UHS-3 or Class 10)





Gimbal

Gimbal Three-axis stabilization
Mechanical range Tilt: -135° to +45°;
Pan: -100° to +100°
Controllable rotation range Tilt: -90° to +30°;
Pan: -90° to +90°
Max control speed (Tilt) 300°/s
Angular Vibration Range ±0.005°





Visible Light Camera

Sensor 1/2 inch CMOS; 48M effective pixels
Lens FOV: 79°
35 mm format equivalent focal length: 25.6 mm
Aperture: f/1.8
Focus range: 0.5 m to infinity (with auto focus)
Zoom 1-16x (up to 4x lossless zoom)
ISO range Video: 100-6400
Photos: 100-3200
Maximum photo size 8000x6000(4:3)
7680x4320(16:9)
4000*3000 (4:3)
3840*2160 (16:9)
Photo mode Single shot
Burst shooting: 3/5 frames
Auto Exposure Bracketing (AEB): 3/5 bracketed frames at 0.7 EV Bias
Time Lapse:
JPG: 2s/5s/7s/10s/20s/30s/60s
DNG:5s/7s/10s/20s/30s/60s
HyperLight: support (under 4K JPEG format)
Long exposure:Max. 8s
HDR imaging: support (under 4K JPEG format)
Image Format JPG (default); DNG
Video format MP4 / MOV format (MPEG-4 AVC/H.264, HEVC/H.265)
Video resolution 8K 7680*4320 p25/p24
6K 5760*3240  p30/p25/p24
4K 3840*2160 p60/p50/p48/p30/p25/p24
2.7K 2720*1528 p120/p60/p50/p48/p30/p25/p24
1080P 1920*1080   p120/p60/p50/p48/p30/p25/p24
Max bitrate 120Mbps

Thermal Camera

Sensor 1 inch CMOS; 20M effective pixels
Lens FOV: 82°
35 mm format equivalent focal length: 28.6 mm
Aperture: f/2.8 - f/11
Focus range: 1 m to infinity (with auto focus)
Zoom 1-16x (up to 3x lossless zoom)
ISO range Video: 100-6400
Photos: 100-12800
Maximum photo size 5472*3648 (3:2)
5472*3076 (16:9)
3840*2160 (16:9)
Photo mode Single shot
Burst shooting: 3/5 frames
Auto Exposure Bracketing (AEB): 3/5 bracketed frames at 0.7 EV Bias
Time Lapse:
JPG: 2s/5s/7s/10s/20s/30s/60s
DNG:5s/7s/10s/20s/30s/60s
HyperLight: support (under 4K JPEG format)
Long exposure:Max. 8s
HDR imaging: support (under 4K JPEG format)
Image Format JPG (default); DNG
Video format MP4 / MOV (MPEG-4 AVC/H.264, HEVC/H.265)
Video resolution 6K 5472*3076 p30/p25/p24
4K 3840*2160 p60/p50/p48/p30/p25/p24
2.7K 2720*1528 p120/p60/p50/p48/p30/p25/p24
1080P 1920*1080 p120/p60/p50/p48/p30/p25/p24
Max bitrate 120Mbps

Remote Control & Transmission

Operating frequency non-Japan:2.400 GHz - 2.4835 GHz;5.725 - 5.850 GHz
Japan:2.400 GHz - 2.4835 GHz;5.650 - 5.755 GHz
Transmission power 2.4G
FCC/ ISED:≤27dBm
SRRC/CE/MIC/RCM:≤20dBm

5.8G (non-Japan) ; 5.7G (Japan)
FCC/ISED/SRRC/MIC:≤27dBm
CE/ RCM:≤14dBm
Max Transmission Distance (unobstructed, free of interference) FCC:9 km
CE:5 km
Real-time image transmission quality 720p@30fps / 1080p@30fps
Maximum bit rate of real-time image transmission 40Mbps
Display screen 3.26'' OLED
854(W) * 480(H)Pixel
Directly preview the video without connecting a mobile phone
Remote controller battery 5000mAh
Run time 3 hours
Charging time 2 hours fast charging
Working current/voltage 1.7A@3.7V
