Autel
Evo Lite Premium Bundle - 4-axis Gimbal 4k HDR Camera 50MP photos, PDAF + CDAF Autofocus System, Obstacle Avoidance and object tracking, 40 mn flight time and +7miles range.
Evo Lite Premium Bundle - 4-axis Gimbal 4k HDR Camera 50MP photos, PDAF + CDAF Autofocus System, Obstacle Avoidance and object tracking, 40 mn flight time and +7miles range.
Regular price
$1,459.00 USD
Regular price
Sale price
$1,459.00 USD
Unit price
/
per
Shipping calculated at checkout.
No reviews
Couldn't load pickup availability
The Nano Lite is a High-Quality Professional drone with a 4k HDR camera capable of 50MB photos on a 4-axis gimbal, and a PDAF + CDAF Autofocus System. It also features obstacle avoidance, active object tracking, and many cinematic shots features while lasting about 40 minutes per flight and having a range over 7 miles.
- World's First 4-axis Gimbal Design
- 1/1.28-inch (0.8-inch) CMOS sensor capable of 50 MP photos and 4K HDR Videos
- PDAF + CDAF autofocus system
- Obstacle avoidance system
- Industry-leading 40 minutes flight time
- Transmission range of 7.4 miles
Specifications
Aircraft
Takeoff weight | 835g |
Dimensions (including blades) |
Folded: 210×123×95mm Unfolded: 427×384×95mm |
Wheelbase | 368mm |
Max ascent speed | 5m/s (sport), 4m/s (standard), 3m/s (smooth) |
Max descent speed | 4m/s (sport), 3m/s (standard), 2m/s (smooth) |
Max level flight speed(no wind, near sea level) | 18m/s (sport), 10m/s (standard), 5m/s (smooth) |
Max takeoff altitude | 4000m |
Max flight time (no wind) | 40min |
Max hovering time (no wind) | 38min |
Max flight distance (no wind) | 24km |
Max wind resistance | Level 7 |
Max tilt angle | 33°(sport), 25°(standard), 25°(smooth) |
Max angular velocity | 200°(sport), 120°(standard), 60°(smooth) |
Operating temperature | 0°C ~ 40°C |
Operating frequency | 2.400-2.4835GHz,5.725-5.850GHz,5.150-5.250GHz |
Transmission power (EIRP) | FCC:≤30dBm;CE:≤20dBm |
GNSS | GPS, GLONASS, Galileo |
Hovering accuracy | Vertical:±0.1m (when the visual positioning is active), ±0.5m (with GPS positioning); Horizontal:±0.3m (when the visual positioning is active), ±1.5m (with GPS positioning); |
Gimbal
Mechanical range |
Pitch: -135°~45° Roll: -45°~45° Yaw: -90°~90° Rotate: -400°~400° |
Controllable range |
Pitch: -90°~30° Yaw: -80°~80° Rotate: -360°~360° |
Stabilization | 4-axis,(horizontal/vertical/tilt/rotation shooting) |
Max control speed (pitch) | 30°/s |
Angular vibration range | ±0.003° |
Camera
Sensor |
CMOS: 1/1.28 inch Effective pixels: 50M Pixel size: 1.22μm*1.22μm |
Lens |
FOV: 85° Equivalent focal length: 23mm Aperture: f/1.9 Focus range: 0.5m ~ ∞ Focus mode: PDAF+CDAF/MF |
Shooting mode |
Automatic mode (P gear): EV adjustable, ISO/Shutter automatic Manual mode (M gear): ISO/Shutter adjustable, EV not adjustable Shutter priority (S gear): Shutter/EV adjustable, ISO automatic |
ISO range |
Video: ISO100 ~ ISO6400 Photo: ISO100 ~ ISO6400 Night scene mode: ISO up to 64000 |
Shutter speed |
Photo mode: 1/8000 ~ 8s Other: 1/8000 ~ 1/frame rates |
Portrait blur | Real-time image transmission portrait blur and photo portrait blur |
Defog mode | Support |
Zoom range |
Digital zoom: 1 ~ 16 times Lossless zoom: 4K: 2 times; 1080p: 4 times Note: 4K: more than 2 times the digital, the following is lossless 1080P: more than 4 times the digital, the following is lossless |
Photo format | JPG / DNG / JPG+DNG |
Photo resolution |
50MP:8192x6144(4:3) 12.5MP(default):4096x3072(4:3) 4K:3840x2160(16:9) |
Photo shooting mode |
Single shot Burst shooing: 3/5 Auto exposure bracketing(AEB): 3/5 shots Interval: 2s/3s/4s/5s (default)/6s/.../60s (DNG min 5s) HDR imaging: 8192x6144/4096x3072/3840x2160 Night shot: 8192x6144/4096x3072/3840x2160 |
Video coding format | H265/H264 |
Video resolution |
3840x2160 p60/50/48/30/25/24 2720x1528 p60/50/48/30/25/24 1920x1080 p120/60/50/48/30/25/24 HDR: 3840x2160 p30/25/24 2720x1528 p30/25/24 1920x1080 P60/50/48/30/25/24 |
Max bitrate | 120Mbps |
Timelapse |
Original image:3840*2160,JPG/DNG Video:4K P25 |
Panorama |
Horizontal/Vertical/Wide-angle/Spherical Original image: 4096*3072,JPG/DNG |
Supported file system | Fat32、exFat |
Video format | MP4/MOV |
WIFI transfer | 20MB/s |
Remote Control & Transmission
Operating frequency | 2.400-2.4835GHz,5.725-5.850GHz,5.150-5.250GHz |
Max transmission distance (unobstructed, free of interference) | FCC:12km;CE:6km |
Operating temperature | 0°C ~ 40°C |
Transmission power (EIRP) | FCC:≤30dBm;CE:≤20dBm |
Battery capacity | 3930mAh |
Max battery life |
~ 2.5h (when charging a mobile phone) ~ 3.5h (when not charging mobile phone) |
Interface type | Type C |
Transmission system | Autel SkyLink |
Realtime transmission quality |
Transmission distance<1km:2.7K 30fps Transmission distance>1km:1080P 30fps |
Transmission bitrate | 90Mbps |
Transmission delay | ≤200ms |
