Intel Core i5 12400F Processor & H610M M.2 Motherboard Combo with Dual-channel DDR4 RAM 8GBx2 3200MHz
Intel Core i5 12400F Processor & H610M M.2 Motherboard Combo with Dual-channel DDR4 RAM 8GBx2 3200MHz
Couldn't load pickup availability
Experience the ultimate convenience and performance with the Motherboard H610 Combo featuring an Intel Core i5-12400F CPU and DDR4 8GB RAM. This all-in-one solution not only streamlines the upgrade process but also guarantees optimal compatibility between components, ensuring a hassle-free and efficient setup. Enjoy the benefits of a seamlessly integrated system, where the motherboard, processor, and RAM work in perfect harmony to deliver enhanced speed, responsiveness, and multitasking capabilities. The motherboard combo simplifies the decision-making process for users, providing a well-matched trio that maximizes overall system performance. Elevate your computing experience effortlessly with this carefully curated motherboard combo, offering a reliable and powerful solution for a diverse range of tasks.
SPECIFICATIONS
Chipset: Intel H610
Onboard LAN: 1x RJ45
With CPU: Yes
Support Memory Type: DDR4
Number of PCI: 1
Storage Interface Type: SATA 3
Storage Interface Type: M.2 (NVMe)
RAID Supported: YES
Application: Desktop
Chipset Manufacturer: Intel
Back I/O Ports: 1x RJ45
Back I/O Ports: VGA(D-Sub)
Back I/O Ports: 2x USB 3.2/3.1 Gen 1
Back I/O Ports: Displayport
Back I/O Ports: 4 x USB 2.0
Back I/O Ports: HDMI 2.0
PCI - E standards: PCI - E 4.0
Socket Type: LGA 1700
Special Function: Cooling Armor
Special Function: Support For Overclocking
Usage Scenario: Enthusiast & Overclocking
Usage Scenario: Gaming
Number Of Memory Slots: 2
Ports: PCI-Express X1
Support USB Type: USB 2.0
Support USB Type: USB 3.2 Gen1
Number of PCIe x 4: 1
Number of PCIe x 16: 1
Onboard Connectors & Header: 24-pin Main Power Connector
Onboard Connectors & Header: 8-pin +12V Power Connector
Memory channel: Double
Number of SATA Ports: 2
Audio Channels: 5.1
Max LAN Speed: 2500Mbps
Quality Certification: ce
Certification: CE
Form Factor: Micro-ATX
Supports M.2 SSD: 2242
Supports M.2 SSD: 2280
Number of M.2: 1
[Motherboard]:SY-Classic H610 motherboard
[CPU]:1*Inter i5 12400F CPU
[RAM]:16G=2*DDR4 8G 3200MHz
![](https://ae01.alicdn.com/kf/Sb894976907304455a65ddf604dc80f9eu.jpg)
![](https://ae01.alicdn.com/kf/Sdb8c32107a0c43499f719a3d3bcb233ef.jpg)
![](https://ae01.alicdn.com/kf/S41559d386cff4cc28544c234884a4c50g.jpg)
![](https://ae01.alicdn.com/kf/S4664520099df4370bc8b1e6a8e860966A.jpg)
![](https://ae01.alicdn.com/kf/S3d2f975178d242afb34a453aaaf705a2f.jpg)
![](https://ae01.alicdn.com/kf/S818839756bad4bf49ea5f847834a5fc3U.jpg)
![](https://ae01.alicdn.com/kf/Sae9c34a491ad4b5ab173869397430654F.jpg)
![](https://ae01.alicdn.com/kf/Sc654b5e905144d66936af76d22aa877cU.jpg)
![](https://ae01.alicdn.com/kf/S5a96d265c7f640e1979de3a860112fb8U.jpg)
![](https://ae01.alicdn.com/kf/S125d40f1967a4c5d988f981d5fde1e060.jpg)
![](https://ae01.alicdn.com/kf/S7ff9fbc235944bc6a61ae1018b41a713i.jpg)
![](https://ae01.alicdn.com/kf/S3047dd3d36d74e7a8f769dd98c23c484S.jpg)
![](https://ae01.alicdn.com/kf/Sc16966ed7c044f2e9a1d847b15a0e83ew.jpg)
![](https://ae01.alicdn.com/kf/S241da49793f44f16b9fe70b2907f9bf2Y.jpg)
![](https://ae01.alicdn.com/kf/S7369b1b46d534764a83eed5c9fbc09a5n.jpg)
![](https://ae01.alicdn.com/kf/Scd50ba8eedd34c79ad0bd8933d875cadJ.jpg)
![](https://ae01.alicdn.com/kf/S831e9c6bff3f4fc68c35cb9acc2cc3edG.jpg)
![](https://ae01.alicdn.com/kf/S1ed66fbca6974fd7bc7330d158ee0636I.jpg)
![](https://ae01.alicdn.com/kf/S52ae2be1dd234ba48eebddcafcd4eab73.jpg)
![](https://ae01.alicdn.com/kf/Sfe88bba498d44054b8ebd6d0503e1d2aZ.jpg)
![](https://ae01.alicdn.com/kf/S62f4a7e4ec224d96bc11adc6f64ee926S.jpg)
SY-Classic H610M Parameters
Model: SY-Classic H610M
CPU socket: LGA1700 (Inte13th/12th generation processor)
Radiator: only supports LGA1700 interface, not LGA115X (please refer to the actual object for the buckle hole)
Chipset: Intel H610 Chipset
Board type: MATX board type (20.5*22.5cm)
Power supply design: 50A high specification Dr.Mos, 8+1+1 phase enhanced digital power supply, 8Pin enhanced contact CPU power supply
Memory specifications: Dual-channel dual-slot DDR4 memory interface
PCIe interface: 1 PCIe4.0X16 enhanced interface, 1 PCIe3.0X1 interface
M.2 interface: 1 PCIe3.0X4 rate interface, supports 2280/2240 specifications,
SATA interface: 3 SATA36G rate interfaces
Video interface: 1 HDMI interface, 1 DP interface, 1 VGA interface; support core display three-screen output
Rear USB interface: 2 USB3.2Gen1 interfaces, 4 USB2.0 interfaces
Front USB interface: 1 set of USB3.2Gen1 interface, 1 set of USB2.0 pins
Fan interface: 4x4Pin fan interface
Onboard button: CLR_CMOS. Easy to clear button
Sound card network card: 5.1 channel sound card, Gigabit network card
Debug light: support (CPU, DRAM, VGA, BOOT)
