MAG Z790 TOMAHAWK WIFI Motherboard with 120GB M.2 SATA SSD and 240GB 2.5" SATA SSD, 12th/ 13th Gen Intel Core, Pentium Gold and Celeron processors for LGA 1700 socket
MAG Z790 TOMAHAWK WIFI Motherboard with 120GB M.2 SATA SSD and 240GB 2.5" SATA SSD, 12th/ 13th Gen Intel Core, Pentium Gold and Celeron processors for LGA 1700 socket
Regular price
$359.99 USD
Regular price
Sale price
$359.99 USD
Unit price
/
per
Shipping calculated at checkout.
No reviews
Couldn't load pickup availability
The MAG series fights alongside gamers in pursuit of honor. With added military-inspired elements in these gaming products, they were reborn as the symbol of sturdiness and durability.
-
Supports 12th/ 13th Gen Intel® Core™, Pentium® Gold and Celeron® processors for LGA 1700 socket
- Supports DDR5 Memory, up to 7200+(OC) MHz
- Enhanced Power Design: 16+1+1 Mirrored Power Arrangement, dual 8-pin CPU power connectors, Core Boost, Memory Boost
- Lightning Fast Game experience: PCIe 5.0 slot, Lightning Gen 4 x4 M.2, USB 3.2 Gen 2x2
- Premium Thermal Solution: Extended Heatsink Design and M.2 Shield Frozr are built for high performance system and non-stop works
- AUDIO BOOST 5: Reward your ears with studio grade sound quality for the most immersive gaming experience
- High Quality PCB: 6-layer PCB made by 2oz thickened copper and server grade level material
Specification
OPERATING SYSTEM | Support for Windows® 11 64-bit, Windows® 10 64-bit |
---|---|
MANUFACTURER NUMBER | MAG Z790 TOMAHAWK WIFI |
PRODUCT CONDITION | New |
CPU |
Supports 12th/13th Gen Intel® Core™ Processors, Pentium® Gold and Celeron® Processors Processor socket LGA1700 |
CHIPSET | Intel® Z790 Chipset |
CPU SOCKET | LGA1700 |
FORM FACTOR | ATX Form Factor |
MEMORY |
4 x DDR5 memory slots, supporting up to 128GB Memory Support 7200+(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/6200(OC)/6000(OC)/5800(OC) 5600(JEDEC)/5400(JEDEC)/5200(JEDEC)/5000(JEDEC)/4800(JEDEC) MHz Max. overclocking frequency: Supports Intel® XMP 3.0 OC Supports Dual Controller Dual-Channel mode Supports non-ECC, un-buffered memory |
LAN | 1 x Intel® 2.5Gbps LAN |
WIRELESS LAN |
Intel® Wi-Fi 6E The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz 1 (160MHz) up to 2.4Gbps Supports 802.11 a/ b/ g/ n/ ac/ ax |
BLUETOOTH | Supports Bluetooth® 5.3, FIPS, FISMA |
AUDIO |
Realtek® ALC4080 Codec
|
MULTI-GPU | - |
---|---|
STORAGE |
4 x M.2 Gen4 x4 64Gbps slots 7 x SATA 6Gb/s ports |
ONBOARD GRAPHICS |
1 x HDMI™ 1 x DisplayPort Support HDMI™ 2.1, maximum resolution of 4K 60Hz Support DP 1.4, maximum resolution of 8K 60Hz |
RAID |
Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices Supports RAID 0, RAID 1, RAID 5 and RAID 10 for M.2 NVMe storage devices |
I/O (REAR) |
DisplayPort 1.4 USB 3.2 Gen 1 5Gbps Type-A USB 3.2 Gen 2 10Gbps Type-A 2.5G LAN Port HD Audio Connectors HDMI™ 2.1 Port Clear CMOS Button Flash BIOS Button USB 3.2 Gen 2 10Gbps Type-C USB 3.2 Gen 2x2 20Gbps Type-C Wi-Fi / Bluetooth Antenna Optical S/PDIF OUT |
EXPANSION SLOTS |
2 x PCI-E x16 slot Supports x16/x4 1 x PCI-E x1 slot PCI_E1 PCIe 5.0 supports up to x16 (From CPU) PCI_E2 PCIe 3.0 supports up to x1 (From Chipset) PCI_E3 PCIe 4.0 supports up to x4 (From Chipset) |
USB (FRONT) |
4 x USB 2.0 1 x USB 3.2 Gen2 Type C 2 x USB 3.2 Gen1 Type A |
USB (REAR) |
4 x USB 3.2 Gen2 Type A 1 x USB 3.2 Gen2 Type C 1 x USB 3.2 Gen2x2 Type C 4 x USB 3.2 Gen1 Type A |
TYPE-C PORT |
1 x USB 3.2 Gen 2 10Gbps (Type-C) 1 x USB 3.2 Gen 2x2 20Gbps (Type-C) |
INTERNAL CONNECTORS |
1 x Power Connector(ATX_PWR) 2 x Power Connector(CPU_PWR) 1 x CPU Fan 1 x Pump Fan 6 x System Fan 2 x Front Panel (JFP) 1 x Chassis Intrusion (JCI) 1 x Front Audio (JAUD) 1 x TBT connector (JTBT, supports RTD3) 1 x Tuning Controller connector(JDASH) 3 x Addressable V2 RGB LED connector (JARGB_V2) 1 x RGB LED connector(JRGB) 1 x TPM pin header(Support TPM 2.0) 4 x USB 2.0 2 x USB 3.2 Gen1 Type A 1 x USB 3.2 Gen2 Type C |
DIMENSIONS | 12.00" x 9.60" |
MANUFACTURER WARRANTY | 3 Year |
